STA328VJ усилитель 2.1 канальный

Wide supply voltage range (10 V - 36 V) ! Three power output configurations 2 x 40 W + 1 x 80 W 2 x 80 W 1 x 160 W ! PowerSO-36 package ! 2.1 channels of 24-bit DDX ! 100-dB SNR and dynamic range ! 32 kHz to 192 kHz input sample rates ! Digital gain/attenuation +48 dB to -80 dB in 0.5-dB steps ! Four 28-bit user programmable biquads (EQ) per channel ! I 2C control ! 2-channel I2S input data interface ! Individual channel and master gain/attenuation ! Individual channel and master soft/hard mute ! Individual channel volume and EQ bypass ! Bass/treble tone control ! Dual independent programmable limiters/compressors ! AutoModes 32 preset EQ curves 15 preset crossover settings Auto volume controlled loudness 3 preset volume curves 2 preset anti-clipping modes Preset night-time listening mode Preset TV AGC ! Input and output channel mapping ! AM noise-reduction and PWM frequency-shifting modes ! Software volume update and muting ! Auto zero detect and invalid input detect muting ! Selectable DDX ternary or binary PWM output + variable PWM speeds ! Selectable de-emphasis ! Post-EQ user programmable mix with default 2.1 bass-management settings ! Variable max power correction for lower fullpower THD ! Four output routing configurations ! Selectable clock input ratio ! 96 kHz internal processing sample rate, 24 to 28-bit precision ! Video application supports 576 * fs input mode
